Product Overview
The Raspberry Pi 3 Model B+ is an enhanced version of the Raspberry Pi 3 Model B, offering improved networking and wireless performance while maintaining the same form factor. With a faster processor, dual-band wireless LAN, and Gigabit Ethernet (via USB 2.0), it is well suited for Linux-based applications, connected systems, and embedded or educational projects with higher performance requirements.
Technical Specifications
-
Processor: Broadcom BCM2837B0, quad-core ARM Cortex-A53 (64-bit) at 1.4 GHz
-
Graphics: VideoCore IV GPU
-
Memory: 1 GB LPDDR2 SDRAM
-
Networking: Gigabit Ethernet (via USB 2.0, effective throughput up to approx. 300 Mb/s)
-
Wireless: Dual-band WLAN 802.11 b/g/n/ac (2.4 GHz & 5 GHz), Bluetooth 4.2 / BLE
-
USB Ports: 4 × USB 2.0
-
Video Output: 1 × HDMI (full-size)
-
Audio: 3.5 mm A/V jack (audio + composite video)
-
Storage: microSD card slot
-
Camera / Display: MIPI CSI camera connector, MIPI DSI display connector
-
GPIO: 40-pin GPIO header
-
Power Supply: micro-USB, 5V (up to 2.5A recommended)
Scope of Delivery
- 1 × Raspberry Pi 3 Model B+
Notes
Operation requires a microSD card with an operating system and a suitable 5V power supply. Optional peripherals such as a case, cooling solution, keyboard, mouse, and monitor are not included. A power supply with sufficient current capacity is recommended due to the increased performance.
Applications
Suitable for connected applications, Linux-based development and testing systems, IoT and edge computing projects, education and training environments, media applications, and embedded or control solutions with moderate performance requirements.
Product safety information
Manufacturer information:
Raspberry Pi Ltd.
Cambridge Science Park, Milton Road 194
Cambridge, Vereinigtes Königreich, CB4 0AB
compliance@raspberrypi.com
https://www.raspberrypi.com
Responsible person:
Raspberry Pi Ireland Limited
Dublin Landings 3
North Wall Quay, Dublin 1, Irland, D01 C4E0
compliance@raspberrypi.com
https://www.raspberrypi.com
"
Industry & Lifecycle Information
Lifecycle Status
Product status: Active
Market launch: March 2018
Product Change Notices (PCN)
Active PCNs: PCN – Raspberry Pi 3B+ Revision 9 PCB (4 March 2022)
Last known PCN: Raspberry Pi 3B+ Revision 9 PCB
Functional impact: Change to new DA9090 PMIC; PCB revision from R5 to R9; supported from firmware version September 2021; no significant form-fit-function changes
End-of-Life (EOL)
EOL notice published: Yes
Last Time Buy (LTB): still open
Last Shipment Date (LSD): currently expected no earlier than January 2030
Current assessment: Active product with announced EOL; the product remains in active status and end-of-life is currently expected no earlier than 2030
The Raspberry Pi 3 Model B+ is used in embedded, IoT and industrial applications and stands out due to improved networking and performance characteristics. Success stories provide insights into real-world applications and serve as inspiration for your own projects.
Support and Information Channels
Official documentation
Central technical reference including datasheets, design guides and product documentation.
Raspberry Pi Forum for Industries
Platform for technical discussions, known limitations and application examples from industrial projects.
Datasheet
Technical detailed description of the Raspberry Pi 3 Model B+.
Responsibility
The information in this document is based on the currently available data from the manufacturer Raspberry Pi. Regular review of lifecycle information is recommended, especially for series production projects.
"
