Product Overview
The EDATEC ED-HMI2020-101C-1208 is a 10.1-inch industrial HMI based on the Raspberry Pi Compute Module 4. It combines a touchscreen display with industrial interfaces, embedded or VESA mounting options and an enclosure design intended for series deployment. This makes the platform suitable for operator panels, visualisation, data acquisition and Raspberry Pi based industrial applications.
Technical Data
-
Display size: 10.1 inch
-
Resolution: 1280 × 800
-
Touch: Capacitive multi-touch
-
Processor: Broadcom BCM2711 quad-core Cortex-A72, 1.5 GHz
-
Memory: up to 8 GB LPDDR4 depending on version
-
Storage: eMMC depending on variant, MicroSD expansion
-
Network: 1 × Gigabit Ethernet, optional Wi-Fi/Bluetooth
-
Additional functions: RTC, EEPROM, security chip
-
Mounting: Front mounting and VESA
-
Power supply: 9 V to 28 V DC
Notes
Exact CM4 population, storage size and optional camera functions depend on the selected version. Wi-Fi and Bluetooth are integrated or prepared depending on the version.
Application Areas
Operator panels, visualisation, embedded HMI systems, industrial user guidance and compact edge applications.
Product safety information
Manufacturer information:
EDA Technology Shanghai Co.,LTD
Room 301, Building 24, No.1661
Shanghai, China, 201899
support@edatec.cn
https://edatec.cn/
Responsible person:
Astradis Elektronik GmbH
Fraunhoferstraße 11a
Planegg, Deutschland, 82152
info@astradis.com
https://www.astradiselektronik.de/
| Item information |
Value |
| Connectivity: |
WiFi |
| Display size: |
10.1" |
