Product overview
The Waveshare PCIe To M.2 Multifunctional Adapter combines two functions on a single board: it connects an NVMe SSD via the PCIe interface of the Raspberry Pi 5 and converts the Pi's two micro HDMI outputs to full-size HDMI sockets. Standard HDMI cables can therefore be used without adapters, and two displays can be driven at up to 4K. The board connects to the Raspberry Pi 5 using the 16-pin PCIe ribbon cable.
Technical specifications
- Compatible with Raspberry Pi 5
- Accepts NVMe SSDs in M.2 2230 and 2242 form factors
- Supported modes: PCIe Gen2 and Gen3
- Booting the Raspberry Pi 5 from the SSD is supported
- Converts the micro HDMI connectors to full-size HDMI sockets
- Dual 4K outputs supported
- Power supplied either via the USB-C port or a screw terminal
- Connects via the Raspberry Pi 5's 16-pin PCIe ribbon cable
- Manufacturer designation: Pi5 Connector Adapter (C)
Notes
Only SSDs using the NVMe protocol are supported. The Raspberry Pi 5, the SSD and the displays are not included. When running two displays together with an SSD, make sure the power supply is adequately rated.
Applications
Building compact desktop or kiosk systems with two displays, digital signage, control and visualisation workstations, and installations where separate micro HDMI adapters and a separate SSD expansion are best avoided.
