Product Overview
The EDATEC ED-MONITOR-101CA is a robust 10.1-inch industrial touchscreen monitor with HDMI input and capacitive multi-touch. The display offers a resolution of 1024 × 600 and connects via HDMI for video and USB Type-C for touch functionality. With its aluminium frame, sheet metal enclosure, IP65-rated front panel and support for embedded front installation and VESA mounting, the monitor is suitable for industrial visualisation, operator panels and embedded HMI solutions.
Technical Data
-
Display Size: 10.1" TFT
-
Resolution: 1024 × 600
-
Brightness: up to 500 cd/m²
-
Contrast Ratio: 800:1
-
Response Time: 25 ms
-
Viewing Angle: 85° left / 85° right / 85° up / 85° down
-
Touchscreen: capacitive multi-touch, up to 5 touch points
-
Touch Interface: USB, 1 × Type-C
-
Video Input: 1 × HDMI Type-A
-
Audio: 1 × 3.5 mm audio jack, stereo output
-
Backlight: LED, brightness adjustment via buttons and software
-
Input Voltage: 12 V to 24 V DC
-
Power Consumption: 10 W max.
-
Enclosure: aluminium frame with sheet metal housing, IP65 front panel
-
Installation: embedded front installation and VESA bracket mounting
-
Dimensions: 257.7 × 159.7 × 29.2 mm
-
Weight: approx. 940 g
-
Operating Temperature: -10 °C to +60 °C
-
Storage Temperature: -20 °C to +70 °C
-
Ambient Humidity: 5 % to 95 % non-condensing
Notes
Touch functionality is provided through the USB Type-C interface and is intended for direct use with compatible systems such as Raspberry Pi platforms. According to the datasheet, the standard package does not include the separate HMI mounting kit for embedded front installation; this accessory is available separately if required. The IP65 protection rating applies to the front side when installed.
Application Areas
Suitable for industrial HMI systems, machine and plant visualisation, embedded platforms, Raspberry Pi based operator and display solutions, kiosk systems and display units for control cabinet and equipment design.
